Unit Specifications
Alternator Design: Brushless
Frequency: 60 Hz
Phase: Single Phase
Voltage: 120/240 V
Sound Level @ 30 ft: 75 dBA
Fuel Tank Capacity: 5 gal / 19 L
Power Generation
Watts (Max / Cont.): 6000 W / 5000 W
Amps @ 120V (Max / Cont.): 50 A / 41.6 A
Amps @ 240V (Max / Cont.): 25 A / 20.8 A
Receptacles & Circuit Breakers
Main Circuit Breaker: 23 A
Number of Poles: 2
1 Receptacle Each: L5-20R 125V T-Lock 20A, L5-30R 125V T-Lock 30A, L14-30R 125/250V T-Lock 30A
2 Receptacles Each: 5-20R 125V GFCI 20A
Dimensions & Weights
Overall Length: 27 in / 69 mm
Overall Width: 22 in / 56 mm
Overall Height: 24 in / 61 mm
Operating Weight: 241 lb / 109 kg
Shipping Weight: 200 lb / 90 kg
Engine Specifications
Engine Make/Model: Honda GX-340
Start Method: Recoil
Engine Power: 9.5 HP / 7.9 kW
Engine RPM: 3600
Fuel Type: Gasoline
Notice: Features and equipment specifications are subject to change without notice.
