BUY or RENT THIS CS Unitec MAB 1300 5" Variable Speed Reversible 20 amp Electric Magnetic Drill TODAY FROM RENTAL TOOLS ONLINE.
This industry leading electric magnetic drill from CS Unitec(model: MAB 1300) is available for rent by the day, week or month - perfect for quick jobs or longer, more complex projects.- Description
-
Details
Features:
- Largest hole cutting capacity in industry - 6" dia.*
- Reversible motor for tapping and reaming
- Infinitely variable torque control and full-wave control electronics
- 4-speed oilbath gearbox
- Automatic internal lubrication
Safety:
- SafeMag™: Green/Red LED magnetic force indicator for safe operation
- CoolMag™: Magnet overheating protection
- Emergency-off function: electronic safety sensor shuts down drill motor if magnet loses contact with material to protect operator and equipment
Max. HoleDia. Twist DrillDia. TappingDia. Power Speeds Options
Ø 6" *Ø 1-3/4"(Countersinkto Ø 3")Ø 1-5/8"(Ream to Ø 2")20 Amp110 Volt30-8050-120130-350210-550RPMMAB 1300 V: adjustable automatic feed and reverse - power feed controls drill pressure to maintain optimal RPM and feed rate - Additional Information
-
Additional Information
SKU 103557-0010 Weight 112 Country of Manufacture Germany Mfr. Model Number MAB 1300 Link to User Manual x Link to Schematics http://www.csunitec.com/pdf_files/schematics/magnetic_drills/CSU-Schem-MAB_1300_Mag_Drill.pdf Link To Catalog http://www.csunitec.com/pdf_files/mag_drills/CSU-MAB1300.pdf Technical Specifications Motor Power 20 Amp / 110 Volt Weight 112 lbs. Stroke 3.35" (12" without retainer) Hole Capacity 6" dia.* Twist Drill Capacity 1-3/4" dia. Tapping Capacity 1-5/8" dia. Speeds 30-80, 50-120, 130-350, 210-550 RPM Magnet Base Size 4-3/4" W x 14" H Dimensions 34-1/2" H x 19-1/2" L x 10" W Magnetic Force (1" plate) 23,600 lbs. Arbor Bore 1-1/4" (3/4" adapter included) Spindle MT4 Automatic Lubrication Included Automatic Feed Order MAB 1300 V *Annular cutter drilling capacity 6” diameter up to 1” thick in carbon steel - Use TCT cutters for large diameters Free Shipping No
