The CS Unitec Air Hammer Drill – Model 2 1266 0010, ½″ geared-chuck version, is a heavy-duty pneumatic tool designed for high-impact drilling in concrete, brick, and masonry (up to ½″ diameter) and convertible to straight rotary drilling for steel and wood. It features a ¾ HP pneumatic motor, stainless-steel gear housing and composite handle for durability and operator comfort.
- Description
-
Details
The CS Unitec 2 1266 0010 Air Hammer Drill is engineered for professional contractors and industrial users who require dependable performance under demanding conditions. With a ½″ (13 mm) geared 3-jaw chuck and a hammer-action mode delivering up to 2,200 blows per minute (BPM) at the press of a trigger, this pneumatic drill is built to conquer concrete, masonry, stone and brick — yet easily switches to straight rotary mode for drilling steel or wood.
Key features include:
- Pneumatic drive: Eliminates sparking hazards and is suitable for hazardous or damp work environments, including underwater applications.
- Durable housing: A stainless-steel gear housing and rugged composite handle ensure long use in the field.
- Compact yet powerful: At approximately 12″ × 8½″ × 4″ and weighing around 7 lbs, it delivers up to 0-950 RPM rotary speed and full hammer-action capability at ~21 CFM air consumption at 90 PSI.
- Versatility: The ½″ chuck accepts standard bits for a range of materials, allowing users to switch between heavy-duty impact drilling and conventional rotary drilling without needing separate tools.
- Ideal for construction, plant maintenance, offshore or underwater operations, and general industrial use, the 2 1266 0010 offers robust build quality and reliable performance for applications where electric tools may not be appropriate.
- Additional Information
-
Additional Information
SKU 141294 Weight 7 Country of Manufacture Mfr. Model Number 2 1266 0010 Link to User Manual No Link to Schematics No Link To Catalog No Technical Specifications Tool Specifications
Model 2 1266 0010 Operating Pressure 6 bar (≈ 87 psi) Motor Power 0.50 kW (≈ 0.67 HP) Free Speed (No Load) 950 RPM Chuck Size 1/2" (13 mm) geared 3-jaw chuck Max. Drilling Capacity – Steel 13 mm (1/2") Max. Drilling Capacity – Masonry 20 mm (≈ 3/4") Air Consumption 0.60 m³/min (≈ 21 CFM) Air Inlet R 1/4" female Length (with Chuck) 320 mm (12.6") Weight 3.3 kg (7.3 lbs) Sound Pressure Level 84 dB(A) Operating Modes Hammer drilling and straight rotary drilling (for steel and wood) Special Features Suitable for underwater use; ATEX II2G Ex h IIB T6 Gb certified Free Shipping No
