Joint Zone K0474 Raptor D Hydraulic Diesel Power Unit 10.5HP Kohler (5-8 gpm) w/ 50' Hose Set Product Guide
How This Power Unit Fits Into A Hydraulic Tool Package
The Joint Zone K0474 Raptor D supplies hydraulic flow at 5 to 8 gallons per minute and a pressure rating of approximately 1900 psi, powered by a 10.5 HP Kohler diesel engine. This power unit supports connected hydraulic tools requiring medium flow and pressure within this range, such as breakers, hydraulic drills, or compact hydraulic attachments commonly used in industrial and construction settings.
This unit includes two hydraulic circuits capable of delivering the specified flow rates and features quick couplers with swivel fittings for connecting compatible hydraulic hoses and tools. The stainless steel frame with large foldable handles and anti-vibration mounts supports jobsite positioning and transport. The integrated oil cooling system with a centrifugal fan allows the unit to supply hydraulic flow over extended operating periods, supporting longer jobs without overheating. This type fits within diesel engine-powered hydraulic power units that prioritize portability and moderate flow delivery.
Power Unit Planning Notes
This hydraulic diesel power unit is intended for outdoor placement or ventilated locations due to its engine exhaust. Position the unit and direct exhaust away from the immediate work face and operators to prevent exhaust exposure. The unit ships by freight typically on a pallet, so planning for unloading with a forklift, loading dock, or liftgate is necessary.
The included 50-foot hose set defines initial hose routing distance but confirm the hydraulic hose length and routing for operator access and to avoid kinks or abrasion. Long hose runs or additional hose length may require larger diameter hoses or a hydraulic power unit with higher flow capacity to compensate for pressure losses through hose friction and coupler resistance.
This unit meets Tier 4 emissions standards but is not approved for use in California, requiring users to comply with local emissions regulations. It has a centralized lifting hook to support mechanical lifting during positioning and relocation. The stainless steel frame and anti-vibration mounts reduce vibration transfer, which may affect adjacent equipment or surfaces.
Consider work location hydraulic-fluid requirements, especially for municipal, near-water, or environmentally sensitive sites. Rental units do not guarantee the hydraulic oil type inside; confirm fluid specifications in advance if required. After use, inspect hoses and couplers for wear or leaks, clean debris from the frame and cooling fan, and verify the oil level or service as required by standard operating procedures.
- Description
-
Details
DOA Raptor D Hydraulic Power Pack
The DOA Raptor D Hydraulic Power Pack is a diesel-powered hydraulic power unit designed for professional contractors, municipalities, utility crews, rescue teams, rental fleets, and industrial maintenance applications. Built by DOA S.r.l., the Raptor D delivers reliable hydraulic power in a compact, portable, and rugged package.
Powered by a 10.5 HP Kohler diesel engine, the DOA Raptor D provides adjustable hydraulic flow from 20 to 30 L/min with working pressure up to 130 bar. For higher-pressure applications, it can deliver up to 200 bar at 20 L/min. This makes it an excellent choice for powering hydraulic breakers, saws, drills, pumps, rescue tools, and other professional hydraulic equipment.
Built for Heavy-Duty Hydraulic Tool Operation
The DOA Raptor D is engineered for demanding jobsite conditions. Its heavy-duty stainless steel frame protects the unit from damage during transport and operation, while the anti-vibration mounting system helps reduce wear on internal components. The power pack is designed for continuous professional use and is ideal for construction, utility, municipal, marine, railroad, and infrastructure applications.
A high-efficiency hydraulic oil cooling system helps maintain consistent operating temperatures during extended use. This allows operators to run hydraulic tools longer while reducing the risk of overheating and downtime.
Compatible Hydraulic Tools
- Hydraulic breakers
- Hydraulic cut-off saws
- Hydraulic core drills
- Hydraulic hammer drills
- Hydraulic chainsaws
- Hydraulic pole saws
- Hydraulic submersible pumps
- Hydraulic trash pumps
- Hydraulic augers
- Hydraulic grinders
- Hydraulic impact wrenches
- Hydraulic rescue tools
- Railroad maintenance tools
- Utility maintenance equipment
Key Features
- 10.5 HP Kohler diesel engine for reliable field performance
- Adjustable hydraulic flow from 20 to 30 L/min
- Working pressure up to 130 bar
- Maximum pressure up to 200 bar at 20 L/min
- Heavy-duty stainless steel frame for jobsite durability
- Double-radiator hydraulic oil cooling system
- Manual throttle control for efficient operation
- Electric and recoil start
- Flush-face hydraulic quick couplers
- Portable design with integrated wheels and handles
- Open-center hydraulic circuit
- Anti-vibration mounting system
Common Applications
The DOA Raptor D Hydraulic Power Pack is ideal for contractors and professionals who need dependable hydraulic power in the field. Common applications include demolition, concrete cutting, core drilling, utility repair, water and wastewater maintenance, underwater construction support, emergency pumping, railroad maintenance, and industrial service work.
Because it is diesel-powered, the Raptor D is especially useful for remote jobsites where electric power is unavailable or where gasoline engines may not be preferred. Its combination of hydraulic performance, durability, and portability makes it a strong choice for professional crews who need a dependable hydraulic power source.
Technical Specifications
Engine Kohler Diesel Engine Power 10.5 HP Hydraulic Flow 20–30 L/min Working Pressure 130 bar Maximum Pressure 200 bar at 20 L/min Starting System Electric and recoil start Cooling System Double-radiator hydraulic oil cooler Frame Stainless steel protective frame Weight Approximately 198 lbs. Dimensions Approximately 33.5 in. x 23.6 in. x 25.6 in. Why Buy the DOA Raptor D Hydraulic Power Pack?
The DOA Raptor D is a professional-grade hydraulic power pack built for users who need dependable performance, rugged construction, and compatibility with a wide range of hydraulic tools. Its diesel engine, adjustable hydraulic output, advanced cooling system, and compact portable frame make it a practical solution for contractors, municipalities, utilities, rescue teams, and rental companies.
For customers searching for a diesel hydraulic power pack, portable hydraulic power unit, hydraulic tool power pack, or DOA hydraulic power unit, the Raptor D offers the performance and durability needed for serious field work.
DOA Raptor D Available in the United States
Rental Tools Online is an authorized U.S. distributor for DOA hydraulic equipment. We offer the DOA Raptor D Hydraulic Power Pack with expert product support, replacement parts assistance, warranty support, and nationwide shipping.
Contact us today to request pricing, availability, or help selecting the right hydraulic power pack for your tools and application.
- Specifications
-
Specifications
SKU 142400 Weight 200 Country of Manufacture Italy Mfr. Model Number K0474 Link to User Manual No Link to Schematics No Link To Catalog No Technical Specifications Weight 200 lbs / 90 kg Dimensions 31x24x26 in / 85x60x65 cm PSI OUTPUT PSI 1900 psi / 130 Bar HYD CONNECTIONS Single-Output PRIMARY OUTPUT 8 GPM / 30 Lpm STARTER Electric & Recoil MOTOR SIZE 10.5HP Gas ENGINE / MOTOR Kohler MADE IN Italy WARRANTY 12 Months Free Shipping No - Product Questions
-
