JW Fishers CHIRP 450kHz / 900kHz Side Sonar Scanner

Thank you for your inquiry.

**Will the data drop into SonarWiz Map for ger-referington?**
Yes, the file format is XTF, SonarWiz can import it for geo referencing and mosaic generation.

**Does the tow fish have a depth above bottom sounder, roll and pitch and a altimeter in the fish?**
The towfish has heading, pitch, and roll and water pressure (depth). It does not have a distance off bottom altimeter.

**What is the min bracking of the tow cable?**
If referring to bend radius, 4" diameter

**Does it have a water block inside the cable and what is the jacket on the cable made of?**
The towcable consists of a single coaxial cable with a Kevlar over-braid for strength. The outer jacket is a durable, high viz yellow urethane.

**What is the max speed it can be towed?**
5 knots is the recommended max tow speed

**What is the turnaround time if it gets damaged?**
This unit is for purchase only. The turnaround time is dependent on the amount of damage and the availability of parts.**

**Does JW Fishers make a 600/1200kHz option?**
There is a 600/1200kHz option available. It is not listed on our website, but we can check pricing and availability if you give us a call at 866-952-8665.
